Custom Parcel Sorting Systems. Engineered for Real Operations.
Custom Parcel Sorting Systems. Engineered for Real Operations.
The Wheel Sorter can be integrated with a Singulation System to improve overall sorting accuracy and efficiency. By separating bulk parcels into a single-item flow before sorting, the system ensures proper spacing and alignment, enabling smoother and more precise diverting.
This combination is especially effective in reducing parcel overlap and sorting errors in high-volume operations.
Share to :
| item | specification |
| Sorting capacity | 4,000 items/hour |
| Conveyor Speed | 1.0 – 1.6 m/s |
| Switching Time | 0.13 – 0.3 s |
| Load Capacity | 60kg |
| Min Parcel Size | ≥ 150 × 150 mm |
| Max Parcel Size | 960mm |
| Sorting Angle | 45° |
| Drive Type | 24V DC roller or servo motor |
| Frame Width | 680mm |
| Working Temperature | +5°C to +40°C |
The 680mm width allows this modular wheel sorter system to be installed in the tightest warehouse spaces without compromising on 60kg load capacity.
The 45-degree angle ensures high-speed parcel diverting with minimal centrifugal force, reducing parcel rotation and ensuring standard cartons stay aligned.
A practical alternative to complex systems, offering reliable performance for distribution centers that require multiple sorting destinations on a budget.
Proven stable performance reduces downtime and maintenance costs.
1.Min: 100 × 100 × 10 mm
2.Max: 500 × 400 × 400 mm
3.Weight: 0.03 – 30 kg
Perfect for small and irregular parcels
1.Carrier pitch: 400 mm / 500 mm
2.Chute width: 700 mm / 1100 mm
3.Speed: 1.0 – 1.5 m/s
Adaptable to different layouts
Powered by 24V DC rollers or servo motors for precise control and energy efficiency.
Proven experience in logistics automation
Customized solutions based on your layout
Stable performance in real applications
Complete support: design, production, installation
Fast response for global customers
We can design a set of logistics transportation sorting system for you tailored to your specific facility dimensions and throughput requirements.
Watch how the system achieves high-speed and high-accuracy parcel sorting in real projects.
Used for sorting parcels by destination, route, or delivery zone.
We’ve compiled answers to some of the most frequently asked questions about selecting, installing and maintaining these systems in a warehouse or distribution center.
Its 680mm ultra-narrow frame width is specifically designed for high-density layouts where space is limited, providing a full-featured modular wheel sorter system in a small package.
A 45° angle allows for much smoother high-speed parcel diverting, which is ideal for maintaining conveyor speed and preventing fragile contents from shifting inside cartons during the transition.
Yes, despite its compact size, it is engineered to handle standard cartons and parcels weighing up to 60kg reliably.
Due to its simple modular structure and reliable DC roller technology, maintenance is minimal, significantly reducing long-term operational costs.
Contact us today to get a custom layout design and competitive pricing for our high-efficiency Wheel Sorter.
